Six-Part Drip Chamber Assembly Machine

Main Features & Functions

● Fully Automatic Feeding System

• Vibratory bowl feeders and conveyors for stable part feeding

• Automatic orientation and precise positioning

● High-Precision Assembly Stations

• Filtering mesh insertion

• Upper & lower chamber hot-melt bonding or ultrasonic welding

• Connector installation

• Cap assembly

• Optional air filter installation

● Online Quality Detection

Equipped with:

• CCD vision inspection (detects defects, missing parts, deformation)

• Leak test system (optional)

• Bonding strength test (optional)

● Output Speed

• 3,600 to 6,000 pcs/hour
  (Speed depends on design and number of stations)

Key Advantages

✔ High Production Efficiency

• Replaces 10–15 workers

• Continuous operation, stable output

✔ High Assembly Precision

• Automatic alignment ensures accurate fit between chamber parts

• Ultrasonic welding creates strong and consistent seals

✔ Stable Quality Control

• CCD cameras detect:

• Wrong placement

• Missing mesh

• Crack

• Welding error

• Eliminates defective products automatically

✔ Clean and Hygienic

• Stainless steel frame

• Suitable for medical cleanroom use (Class 100,000 / Class 10,000)

✔ Easy Operation

• Touch screen (HMI)

• PLC control (Mitsubishi / Siemens / Omron)
